Description

The Canon imageRUNNER 2224 (IR2224) is a reliable, high-efficiency A3 monochrome digital multifunctional laser printer engineered to streamline daily document workflows for small to medium-sized offices, workgroups, and commercial printing hubs. Delivering print and copy speeds of up to 24 pages per minute (A4) with sharp 1200 x 1200 dpi output quality, this compact A3 desktop unit combines printing, copying, and color scanning into an economical, space-saving footprint.

Designed for straightforward, daily business operations, the IR2224 features an intuitive 8.9 cm (3.5-inch) monochrome touchscreen display, a fast warm-up time of 13 seconds, and a robust 1.6GHz dual-core processor. With standard paper handling of 350 sheets (250-sheet cassette + 100-sheet multi-purpose tray), high-yield C-EXV 42 toner support, and energy-efficient operation, it ensures consistent output with low overall operating costs.

Key Features

• A3/A4 All-In-One Functionality: Integrates high-quality black-and-white printing, copying, and color scanning up to A3 document sizes.

• 24 Pages Per Minute Speed: Produces output at up to 24 ppm (A4) / 12 ppm (A3) with a quick first-copy-out time of 7.4 seconds.

• 3.5-Inch Touchscreen Interface: Clear 8.9 cm monochrome touchscreen panel simplifies job setup and menu navigation.

• Fast Warm-Up & Recovery: Boots up in under 13 seconds from power-on and recovers from sleep mode in just 4.3 seconds.

• Flexible Media Handling: Standard 350-sheet capacity (250-sheet paper drawer + 100-sheet bypass tray), expandable up to 600 sheets with an optional cassette module.

• Cost-Efficient Output: Built to work with high-capacity Canon C-EXV 42 toner and drum units to minimize cost per page and maintenance downtime.

Technical Specifications

• Model / Part Number: imageRUNNER 2224 / IR2224 (5942C001AA)

• Brand: Canon

• Functions: Print, Copy, Scan

• Engine Speed (A4 / A3): A4: Up to 24 ppm / A3: Up to 12 ppm

• Control Panel: 8.9 cm (3.5 inch) Monochrome Touch Panel

• Processor / Memory / Storage: 1.6 GHz Dual-Core Processor / 1.0 GB RAM / 2 GB eMMC

• Print / Copy Resolution: Up to 1200 × 1200 dpi (Print) / 600 × 600 dpi (Copy)

• Paper Size (Min – Max): Multi-Purpose Tray: Min. 95 × 148 mm up to A3 (297 × 431.8 mm); Paper Cassette: A5R to A3

• Standard Paper Capacity: 350 Sheets (250-Sheet Cassette + 100-Sheet Multi-Purpose Tray)

• Maximum Paper Capacity: Up to 600 Sheets (with optional Cassette Feeding Module-AK1)

• Paper Output Capacity: Standard 250 Sheets

• Supported Media Weights: Multi-Purpose Tray: 60 to 157 gsm; Paper Cassette: 64 to 90 gsm

• First Copy Out Time: Approx. 7.4 seconds or less (A4)

• Warm-Up Time: 13 Seconds or less from Power On (4.3 Seconds from Sleep Mode)

• Connectivity Interface: Standard USB 2.0 (Device) × 1

• Printer Language (PDL): Standard UFRII

• Consumables: Canon C-EXV 42 Black Toner (~10,200 pages) & Drum Unit

• Dimensions (W x D x H): 627 × 589 × 502 mm

• Net Weight: Approx. 32.3 kg (including toner)

• Condition: Brand New
